Credible, Reliable, and Expertized production line in precision gear.

Taking care of the entire process of designing, constructing, and manufacturing, we are responsible to deliver a complete product to our customer.
We take care of designing and construction of reduction drive, helical gear, planetary gear machine, worm wheel, and bevel gear.

Transfer robot parallel shaft speed reducer

Specification
Rating 3.5kw
Input rotation 3000rpm
Output rotation 1500rpm
Speed ​​ratio  1/2
Weight  8kg

Transfer robot planetary reduction gear

Specification
Rating 3.5kw
Input rotation 2000rpm
Output rotation 222rpm
Speed ​​ratio  1/9
Weight  12kg

Conveyor parallel shaft speed reducer

Specification
Rating 500kw
Input rotation 1200rpm
Output rotation 94.1rpm
Speed ​​ratio 1/12.751
Weight 5500kg

Leveler distribution reduction gear

Specification
Rating 55kw
Input rotation 507.4/724.9rpm
Output rotation 507.4/724.9rpm
Speed ​​ratio  1/1
Weight 1000kg

Worm reducer


Specification
Rating 15kw
Input rotation 300rpm
Output rotation 20rpm
Speed ​​ratio  1/15
Weight 200kg

Lift lifting speed reducer

Specification
Rating 7.5kw
Input rotation 1160rpm
Output rotation 26.31rpm
Speed ​​ratio 1/44.07
Weight 320kg

Conveyor speed reducer

Specification
Rating 300kw
Input rotation 1200rpm
Output rotation 94.604rpm
Speed ​​ratio 1/12.684
Weight 3800kg

Hoisting machine for parallel shaft speed reducer

Specification
Rating 37kw
Input rotation 1152rpm
Output rotation 66.56rpm
Speed ​​ratio 1/17.307
Weight 1225.9kg

Inverter reel speed reducer

Specification
Rating 1.5〜2.2kw
Input rotation 36rpm
Output rotation 12.05rpm
Speed ​​ratio 1/3.04
Weight -kg
